Blitz Basic Worklog
· 26/10/2000
I've had a very satisfying couple of days playing around with the 3d collision code.
I dropped the full-on polygon collision idea, and instead concentrated on simple(!) sphere/polygon collisions. And they work very, very nicely!
As a bonus, Blitz does the collision-avoidance thing for you automatically. This is no mean feat to program, and is something that doesn't seem to be addressed by any game creation systems or languages out there.
The speed's still not quite there, as the algorithm iterates over every polygon in the scene. However, when I finally get some kind of bounding/culling-tree thing happening this can be used to speed up collisions too.
Before I get into that, though, it's probably time for a big cleanup of the 3D code. One of the tricky things about writing 'new' code is that you don't quite know where it fits into the overall scheme of things. I've now got a much better idea of how it should all hang together, so it's probably a good idea to re-arrange some stuff before I get too carried away!
· 18/10/2000
Are we there yet? Yes, I think we are. Mass production of Blitz should be happening right about NOW!
I've had a bunch of late nights, fixing up many, many stupid little things, sending Guildhall the wrong version etc etc, but the end result is entirely to my satisfaction.
There are a ton of things I would like to have added for the release, but this would probably have pushed the release date back to, say, 2035.
As it is, though, the mighty internet means it is now possible for me to constantly add things to Blitz, and for people to have immediate access to new versions. This is a very, very good thing, and I intend to make the most of it. Expect Blitz to become a dynamic, growing thing...
On the 3D front, I have animations going after a few days of head-scratching.
I was mildly surprised to find that the X file format stores it's anim rotation data as quaternions. Surprised because it's not documented. I have had little to do with these cool sounding beasts, but a couple of hours on the 'net has armed me with enough knowledge to get them working.
Quaternions are a way of representing rotations that apparantly make for smoother rotational 'tweening'. My sadly unartistic eye was, however, unable to tell the difference between 'slerping' and 'eularing', but slerping has the better reputation so it stays.
I've also added commands for people to set up their own animations. Not totally sure why, but it was doable so I did it.
Collisions were put on the back-burner until the final Blitz release is out the door, but I expect to be getting back into them real soon.
· 1/10/2000
Hurrah! Woah! Yes! The final version has been sent to George at Guildhall for his expert polishing touches!
Of course, I promptly received an email to the effect that it didn't actually work, but this was soon fixed. This was due to my last minute decision to make variables case-insensitive - something that should've been pretty trivial, but ended in the cleaning up a fair bit of related code: and breaking it. Should be fine now, though.
Variables being case sensitive was really a big oversight on my part in the first place. After being repeatedly reminded that it kind of sucked, I have relented and am suitably humbled.
Progress has also been made on the 3D front. X models are loading (pretty rare format, I know, but its well documented so makes a good starting point) and some spheres and cubes are flying around. Nothing too spectacular, but its getting there.
I spent a bit of time today sketching out ideas for collision algorithms, and came up with a nifty convex hull-to-polygon idea that'll make for a good starting point. I'm not totally sure how useful polygon-to-polygon collisions actually are for a game - I've never tried them, though I can imagine they're pretty slow. Anywho, a convex hull/polygon collider should allow for high speed collisions with a reasonable amount of accuracy - certainly good enough for any commercial games out there right now.
So, my goal for the end of the week is to have a space-ship flying through a 'cube city', complete with collisions and an overhead camera view. I'll let you know how I get on...
· 26/9/2000
Things have been hectic! I've been working mainly on the final release, ironing out problems and bugs, and on the docs every now and then. Everything is just about there, and it looks like Blitz will make its September deadline (just)! There are a few things I would really like to have added, but I'd rather get the release as solid as possible first and provide these as updates on the web-site later.
I've also been tinkering with some 3D at last! Nothing too flash, but object hierarchies with cameras, lights and the obligatory sphere are going. Objects in the hierarchy can all be moved, scaled, rotated etc. regardless of type. So, instead of MoveCamera/MoveLight etc there is just the one MoveObject. Objects are assigned a parent when they're created, and I'll eventually add commands to change the parent dynamically. This will be useful for 'picking things up' - eg: humanoids!
In terms of performance, I was a bit nervous about using D3D transform and lighting but it has turned out to be acceptable without HW T&L (Hurah! I get to use that acronym at last!). And, if you want to provide support for all the D3D goodies, you pretty much have to go through the D3D geometry pipeline. So I guess this time round I'll be doing things the 'correct' way. Boring!
The much underrated art of collision detection will probably be my next area of inquiry. This is quite possibly one of the most overlooked aspects of 3D programming, and is typically the defining difference between a 3d demo and a 3d game. My experience with G-Tok will be useful here - even though it was programmed around a specialized engine, there are still quite a few ideas I can re-use.
I also splashed out on some research material, in the form of a PC games mag/CD. I normally don't buy these anymore as PC games generally leave me feeling pretty uninspired and strangely depressed (I'm an N64 gamer at heart!), but in the interests of the 3D project I decided to have a look at the latest 3D goodies...
What always strikes me first about PC 3D games is the profound lack of colour. Everything is shades of grey/grey-green/grey-blue/grey-whatever. I guess this has to do with 'realism' or something, but it really hilights to me how narrow the PC gaming mindset has become.
The next thing is that I ALWAYS have to reach for the brightness control in PC games! It's probably just my rapidly deteriorating eyesight, but the end effect is that the graphics just end up looking even blander.
Finally, PC games are always so goddamn serious! You're always on a 'very important mission' of some kind, and in the end have very little freedom within the gaming world. There is very little humour, and I find many of them verge on unintentional self-parody.
Ok, these criticisms are totally subjective, and reflect my preference for the greater freedom and abstract fantasy of Mario64/Banjo/Zelda type games, but why are there none of these types of games on the PC? The PC has always been unusually off-limits to certain gaming styles - eg: beat'em'ups and platformers never quite worked on the PC - why? Weird.
Hmm...got a little side-tracked there...
· 17/9/2000
Well the public demo is out, and things appear to have gone pretty smoothly.
My main concern - that it would die on 99.9999% of the machines out there - was, fortunately, unrealized. There have been a few problems, but nothing too scary.
My other concerns - that the lack of 'impressive' demos and docs would hurt - seem to have been partly justified.
Still, I've had lots of positive feedback, and on the whole am happy with life. Not counting a nasty cold and a radiosity assignment due Thursday...
In a way, this demo release kind of feels like a new beginning - sort of like the day Blitz ran it's first bit of code (ahhh).
I'm now working in bursts on some docs. This is definitely not my favourite part of writing BASIC compilers, and I only hope it doesn't show in the final product. But the command and language references are pretty much done, and Claire is doing an excellent job at converting them from Sibly-readable format to human-readable.
Of course, what I'm really itching to get stuck into is some real-time three dimendional graphics!
I've spent many hours over the past couple of months sketching out ideas for a fast and flexible engine, and have come to the interim conclusion that the two are as mutually exclusive as programming skills and artistic talent!
But I am determined to produce an engine as flexible as possible. In particular, I don't want to create an engine that does, for example, great in-door scenes, but lousy out-door ones!
Still, I have a few ideas floating around up there that I'm looking forward to trying out. In particular, aggressive view culling will pretty much benefit any type of engine, so I'll be putting a fair amount of work into this to start with.
· 17/9/2000
It's been a looooooong time since the last update - but I can explain!!!
Well, OK, I can't really, except to say I've been really busy and there's lots of new stuff in.
Firstly - multiplayer!
I was really dreading this. Seeing what a hash DX has made of a graphics API, I was kind of nervous about how twisted an API they could come up with for networking. But, DirectPlay is not too bad! In fact, I'll stick my neck out here and go as far as to say it's very good!
On the extremely small chance anyone from Microsoft is reading this, I have only 2 real complaints - no game clock (please? for parametric stuff?), and DDSESSION_MULTICASTSERVER is broken. But, apart from that, good work guys...
The commands are player based. You add/remove players with CreateNetPlayer ()/DeleteNetPlayer (), and proceed to send messages around. It all works remarkably well. I was also very impressed with the built in server migration feature. This means that if you host a multiplayer game, then quit, the game automagically moves across to another player. Nifty.
Unfortunately, it doesn't solve the 'deeper' problems of net gaming - lag and bandwidth. But, it's a start...
Next up is the ability to render to any image via the SetBuffer command. This much requested feature has been responsible for a slew of 'retro' type demos amongst the testers, which I'm not totally sure I approve of. Still, it's nice to see the PC doing stuff that runs SSSMMMOOOTTTHHH!
Finally, you can now create executables!
·
8/8/2000
Hmm, not a
lot to report, but I'm kind of bored so thought
I'd write some stuff anyways...
Perhaps the
major thing to note is that Blitz now has a
simple debugger. It provides a combined
call-stack/variable-watch tree control you can
inspect while your program is stopped or tracing.
Nothing too fancy, but I'm already finding it
useful myself.
There's a
fair bit of pressure on at the moment to add
Windows GUI support to Blitz. Fair enough, as
many of the AmiBlitz users got into Blitz for
it's Amiga GUI support. These are also the people
showing the most interest in Blitz at the moment,
so I find this totally understandable.
However,
GUI support for Blitz is not my immediate goal.
Ideally, I'd rather get a decent library system
into Blitz and let someone else tackle this! At
the moment, my goals for Blitz are still cool 3D
and a solid library system.
·
29/7/2000
Wow, what a
day! I've finally solved 2 major problems within
the space of about 8 hours!
First up,
people have been reporting speed problems - ie:
Blitz progs were running very slowly in certain
graphics modes. The problem appears to be that
not just different video cards, but different
display modes have different capabilities. This
had kind of occured to me, but I couldn't think
of a way to determine which display modes were
the problem ones. Anyway, there is, and it turns
out to be ridiculously simple. VERY MUCH my
fault, but when you're trying to debug something
on a machine 2000 miles away it's easy to
panic!!!!!
Secondly,
Blitz now works under Win2000! I have finally
taken the plunge and installed the beast - still
using Win98 for development though - and was
incredibly happy to find Blitz was just 1 fix
away from working 100% Woohoo!
·
27/7/2000
Sorry about
the lack of updates, but it's been a fairly
uninteresting 'fix-lots-of-bugs' period. This is,
of course, a good thing, but doesn't make for
terribly gripping reading.
I have
received lots of 'put this in' requests, but am
trying fairly hard to stick to my primary goal of
making Blitz solid and bug-free. While I'm under
no illusions about releasing Blitz with NO bugs
in it, I'd like to minimize problems as much as
possible. However, some feature requests are very
sensible - revealing a distinct lack of foresight
on my part - and have been implemented. I'm not
going to mess with language features too much
from here on in - at least not until BlitzPro
time - but new, simple commands are no problem.
People have
been knocking together some quite nice demos too
- check out the examples page. Unfortunately,
executables aren't available yet so you'll just
have to stare at the code and wonder...
·
21/7/2000
Well, it's
been an incredibly nerve-racking couple of days.
For reasons totally unclear to me, one of the MFC
methods decided to start behaving completely
differently. The problem appeared after
installing the latest 3DFX driver (worst
installer I've ever seen), and boy was it scary.
After installing the driver, I started Blitz up
and was mildly(!) surprised to find that all the
demo programs appeared completely garbled in the
editor. On top of that, NOTHING would compile.
Two days later I had finally tracked the problem
down to the GetLine() method - it just appears to
work totally differently than it used to. I guess
the 3DFX driver must have installed an MFC dll
that works differently - I'm just amazed at how
differently it works! Anyway, the problem is
fixed, and I've had confirmation of the problem
via the experts exchange site.
Reading the
docs for the GetLine() method I can see that it
could work either way but, like DirectX, the docs
are extremely vague, consisting of only a few
sentences.
I also
threw together a 'Firepaint' demo. This simply
generates explosions when the mousebutton is held
down, but looks very cool! It also makes for a
good speed test, with hundreds of particles
flying all over the place.
With the
GetLine() problem out of the way, things are
starting to look very finished. Look out for a
demo soon!
·
16/7/2000
Yet another
discussion group started! There were lots of
requests to move things over to e-groups, so it
is done. I think you have to register or
something, but it looks pretty groovy. Go here.
Had a bit
of a relax today and when on a minor
'coffee-crawl' around Auckland. Did manage to put
in saving of window-size/general preferences,
though.
I've been
hammering Blitz quite a bit lately, and it's
looking really solid. No crashes so far, although
some of the error messages are a bit confusing -
must fix. However, as with anything PC-related
the real test is how well it works on EVERYONE's
machine. Hopefully, the beta release in a few
weeks will uncover any of the nastier problems.
There are
still a few memory leaks, but I'm pretty sure I
know where they're at.
·
15/7/2000
Well, I've
been putting this off in the hope I would
gradually change my mind about it, but that
hasn't happened so here we go: The DirectX rant:
DirectX
really, really sucks! Why?
- Amazingly
convoluted and downright 'weird' API.
Although this can be said of pretty much
the whole Win32 API, they seem to have
gone to extra lengths with DirectX.
- Slow.
Ok, it's pretty hard to beat hardware
accelerated Blits, 3D etc, but whenever
the software has to do anything it seems
to ALWAYS be better to write your own,
naive version. Examples? Clipper objects
- clip 'em yourself for a non-trivial
speed boost. Transformations? Ditto. A
hacked up for...next matrix multiply goes
faster. Direct3DSound? I have no idea
what they did to this, but doing your own
doppler-shift/3d pan/fadeout effects on
top of DirectSound is about 3X faster.
- Incredibly
Non-deterministic. Basically, NOTHING in
DirectX is guaranteed to actually work -
EVERY call you make has to be checked to
see if it succeeded! This places an
incredible burden on the programmer, and
is certainly unnecessary.
- Very
poor documentation. There are a million
'gotchas' to watch out for in DirectX,
very few of which are documented.
Important topics like interaction with
Windows are given about a paragraph,
while whole chapters are devoted to
non-DirectX stuff like 3D pipelines.
Weird. Still, I get the feeling not even
Microsoft know how DirectX works anymore.
On the ONE occasion I've actually
received a reply from
directx@microsoft.com, they only had
answers to 2 of my questions - one of
which was useless, and the other just
plain wrong.
It's really
scary to think that the people responsible for
this are subtly 'guiding' the development of PC
gaming hardware - in the sense that it's now
pretty much an 'AHAL' (abstract hardware
abstraction layer!). Whatever junk they throw in
to DX the hardware manufacturers are gonna feel
obliged to implement. Yeuck.
·
12/7/2000
Spent the
last few days tidying up lots of little problems
and tweaking various commands. Almost all the
menus are functional now!
I also
started work on 'release' mode. This is where all
the runtime checking is turned off and your code
just FLIES! Up until now, every statement in the
program was making a windows PeekMessage() call
before it executed. This is disabled in release
mode, and although the speed difference is
noticable it's not as great as I thought it would
be! Array checking goes in release mode too, so
make sure your code's cool.
I'm yet to
put in any serious work on runtime error
checking. So far, I've been relying on windows
exceptions to let me know when something's wrong,
which work nicely but is a bit obscure. Most
runtime errors result in an 'Illegal memory
address' error message, which is not very useful.
Got to get on to this...
All up,
Blitz is starting to look very much like a decent
package. Hopefully, the beta in early August is
still a reality...
·
6/7/2000
A major
clean up of the command set is just about
finished. I got default parameters going for
functions - within Blitz, too! - which slims the
command set done quite a bit. Also put in a nice
Select...Case...End Select, that works for ints,
floats and strings, and allows multiple
expressions per case.
ResizeImage
and RotateImage went in very sweetly. As they're
intended for creating pre-calculated images, and
not for real-time use, I could afford to do
something a bit tricky, so put in bilinear
filtering. The end result is scaled, rotated
images that are very smooth. It's even possible
to rotate by less than a pixel, but still notice
the rotation! I took a huge sprite, rotated it
through a tiny arc, and you can definitely notice
it swaying. Or so I've convinced myself...
I also put
in a very cheesy console mode, basically so
people (myself included) can mess around with
various non-graphical commands. It's not meant to
be used seriously, but it at least gives Blitz
simple Print/Input capabilities. I'm eventually
going to convert all the (non-C++) filesystem
stuff over to Posix too, meaning the 'core' of
Blitz should be buildable on quite a few
platforms...
Check out
the commands page - most of the major stuff is
now in.
·
30/6/2000
Well, it's
been a slow but rewarding couple of days. Pixel
perfect collisions are finally happening, after
much scratching of head and general 'humm'ing and
'hahh'ing. Actually, it felt a bit like a return
to the old Amiga days - stuffing around with
shifting and last-word-masks - but the results
are worth it. Could also be a good candiate for
assemblerizing. Still, it ALWAYS pays to see what
kind of asm VC has produced as it's often very,
very good.
I also put
in DirectMusic support. It's a huge package, and
feels a little like overkill just for the sake of
letting people play music files. I don't think it
plays anything but Midi, either - the docs are a
bit vague on this (and that, and that...). It
would probably pay to put in support for good-old
winmm.lib too, as I think this is more flexible.
Still, there's a lot in DirectMusic that someone
with a more musically inclined brain would
probably understand, so it could make good fodder
for BlitzPro library writers.
Also
reduced(?) constant expression trees in
preparation for a 'Const' variable type and
default function arguments. Up until now, an
expression like 'a=100-50' would have generated
code for the subtraction. But no more! I really
want to get default function args in ASAP, as the
library command set is looking pretty bloated at
the moment.
·
27/6/2000
Whew, just
knocked off about 30 BASIC commands! Mainly
string handling and fileio stuff - not much fun,
but working in C++ made it about 100 times more
bearable than it was in the bad-old 68000 days!
God, I'm glad I'm over assembler, but still have
a huge respect for the guys out there still
hacking (in the REAL sense of the word).
Animating
images are in, and pretty simple to use.
LoadAnimImage just grabs a sequence of cells from
a .bmp and DrawAnimImage is used to draw a cell.
Animating images and normal images are really
just the same thing, except normal images have
only one frame. I may actually drop DrawAnimImage
and use an ImageFrame command instead to prevent
the number of Image commands balooning. On the
other, hand I don't like 'state' stuff very
much...
Only 3
serious things I have yet to do with Images.
ResizeImage, RotateImage and some kind of
pixel-perfect collision routine. I know of no PC
hardware that allows for collision checking like
the good old AmiBlitter, so I'll probably have to
create bitmask images for collision purposes. Not
too major, just messy...
I've also
replaced the 'commands' section of this page with
a link to an automatically generated document
that reflects exactly the commands present in
Blitz.
·
24/6/2000
There comes
a point in any project where you suddenly feel
like, 'wow, this is starting to look like
something cool'. It's usually triggered by some
minor addition, and is usually a total surprise.
In games, it's quite often the addition of a
title page. It happened the other day with Blitz,
and it was caused by simply adding a 'compiling
progress' meter. Suddenly, it felt like I was
using a real piece of software...weird.
Emboldened
by this small step for Mark-kind, I got back into
the IDE and added a whole bunch of trivial stuff.
The difference is amazing, and Blitz is starting
to 'feel' really, really good! True to form, I'm
not quite doing the IDE the 'proper' way (ie MFC
MDI app). This is partly because reading MS
documentation is too much like real work, and
partly because I just like to do things
differrently! Anyway, it gives Blitz a certain
unique feeling that I am well pleased with.
I added a
whole bunch of sound commands the other day.
DirectX is pretty good in this department, once
you've got your head around the WAVEFORMATEX
structure. Anyway, sounds are playing happily
away and all is good.
Also added
my own 'new' and 'delete' operators for debugging
. I'd been using Visual C's DEBUG_NEW up until
now but, like so much of Microsoft's stuff, you
spend a LOT of time trawling through endless docs
looking for a tiny feature before saying to
yourself 'This is crazy. I could do this myself
in half an hour'. So I did. The upshot is I have
a very nice memory leak detector built in to
Blitz, and have been hitting in mercilessly.
·
20/6/2000
There is
now a BlitzPC discussion group, where people can
put forward Blitz ideas and just generally
shoot-the-breeze!
·
15/6/2000
Another
highly successful day! I had decided today was
gonna be a big 'fix all the memory leaks' day,
and expected it to be a long, drawn out hassle.
Fortunately, it wasn't, and by midday I was
twiddling my thumbs looking for something else to
do. I decided it was time to have a go at
generating some stand-along executable code -
something I've been putting off until the program
format had stabalized a bit. A few hours later
and it was all go - spacies at the click of a
button! This is very cool, as I can now start
sending out some executables to people and suss
out compatibility issues.
·
14/6/2000
Wow, long
time without an update. I've been working madly
away and am happy to say that Blitz is coming
along very, very nicely. Floating point is in
(except for one tiny problem), NewTypes are
happening, and I've written a little Space
Invaders!
The
NewTypes thing has been implemented very
differently from the original Blitz. For
starters, everything is now a pointer. To create
an instance of a NewType (an 'object'), you use
the 'New' operator. To get rid of an instance,
you use 'Delete'. All New'd object are maintained
in a global list, giving you quick 'n' easy
access to all objects of a particular type. For
example, here's how my space invaders code
updates the aliens:
for
a.Alien=Each Alien
UpdateAlien( a )
next
You can
achieve the same thing manually:
a.Alien=First
Alien
while a<>Null
UpdateAlien( a )
a=Next( a )
Wend
Other cool
things: you can Delete an object, but still use
Next or Prev on it. Deleting an object will
automatically force all pointers to it to 'Null'.
You can delete all instances of a Type with
'Delete Each' - great for end of level clean-up,
and it's nice to know all those objects really
are deleted.
Best of
all, the horrible aliens() current object thing
from AmiBlitz is no more.
This system
is not quite ideal. Objects are maintained in
only one list, although it's no problem to
manually create your own lists C-style. In my
experience this isn't too much of an issue,
particularly with games, but might bug people who
want more flexibility. I will probably explore
mulitple lists at a later time, but right now I'm
very happy with this set up as a core memory
management system. Other stuff can be layered on
top.
I've also
been playing with the idea of allowing objects to
specify states, maybe like this:
NewType
Alien
var x,y
state active,angry,happy end newtype
for
a.Alien=Each Alien[ angry And active ] ...
Enormously
useful for games, but we'll see...
Other
things I've been up to:
- Array
bounds checking is in.
- Temporaries
cleaned up at function exit.
- Major
sexification of code.
On the
topic of functions, It's looking like Gosub might
have to bite the dust in Blitz - too much of a
headache to implement cleanly. It would also
simplify things to throw out Goto as well, but
I'd probably end up with a bunch of angry Basic
programmers out for my blood. Besides, I like
having it in there just to piss off the purists.
·
23/5/2000
Yay! Back
into some real programming! Finally put in some
decent register spilling, which seems to be
working well. The actual spilling code isn't too
hard, but Intel's instruction set makes for some
'interesting' problems. In particular, certain
instructions need their operands in particular
registers - eg: divide requires the divisor to be
in EAX:EDX; bit shift instructions require the
shift amount to be in ECX. But it's making a
pretty good attempt to ensure these requirements
are met, thus causing fewer spills.
This has
really been a lead-up to putting in floating
point, which I am starting on right now...
·
22/5/2000
Woah, sorry
about the lack of updates but it's been a week in
Windows HELL! I learnt a lot more about DirectX
and MFC than I'd really like to know, but it's
all been fairly productive. Your code can now be
run in either 'debug' or 'execute' mode. Debug
mode copies it's output to a window, and allows
you to stop/step through the code. Execute mode
runs full-screen, but you can only pause or
continue execution. Not entirely what I was
after, but a good compromise.
Syntax
hilighting now in, although my color scheme
leaves a lot to be desired! It's not very fast at
the moment, but fast enough. I'll probably soup
this up a bit later - the initial coloring when a
file is first loaded is a bit slow.
·
12/5/2000
Put in
forward referencing for functions, and functions
returning values - hurrah! You can also forward
reference arrays and simple vars, but I may take
this out. It's probably time to put in some
floating point - a bit of a hassle due to x86 FP
being stack based. In fact, a complete overhaul
of the register allocator - which doesn't even
spill yet! - is probably in order.
·
11/5/2000
Spent some
time changing the runtime/debugger interface. The
IDE and runtime are designed to run in separate
threads. Before, some of the runtime thread code
was in the IDE project, which I wasn't too happy
with. Now all the runtime thread code is in the
runtime project - much nicer.
Also
implemented the 3 graphic modes the runtime can
execute in - stand-alone, fast-windowed and
slow-windowed. Stand-alone is full screen/full
speed mode. Fast-windowed simulates double
buffering by using 2 offscreen videomem buffers,
while slow-windowed uses one offscreen video
buffer and 2 offscreen system buffers.
Slow-windowed is mainly for graphics cards
without much videomem, or projects which consume
a lot of videomem. However, windowed mode will
probably always consume more memory than
stand-alone, so it's probably a good idea to make
sure the IDE can handle only having a stand-alone
mode.
|
